Bob nick wrote:
1.管子內部如果卡太多油泥熱車油泥變軟後就會有油漬，應該針對管子看是要清還是要換
謝謝Bob nick回文
管子換了大概快1年了算是新的，車子當然是舊的
我的2T車是一模一樣的車都是PGO快活110，都是我在騎，因為車少沒人討論所以到這裡同是2T的園地來長知識。
感謝指點
范代九郎 wrote:
謝謝Bob nick...(恕刪)
這台車真的冷門，機油泵浦跟DIO還有GOING很像
這型的機油泵浦插入KS那條O型環還滿容易壞的，這樣機油會從這裡洩出來而量變少
你2台車白煙的狀況不一樣可以檢查看看那台沒白煙的，或許是O環壞了導致進入汽缸的機油量變少....
以下是PGO原廠手冊潤滑系統故障排除原文
2.Troubleshooting.
A. If there is too much white fume from exhaust system, which means too much
Carbon piled up on the spark plug or the oil quality is not good.
B. Engine over heating:
a. The adjustment of oil pump is not properly.(Lack of oil)
b. The quality of oil is not good.
C. Piston over burning.
a. There is air in the oil pump system.
b. Oil pump is out of order.
D. The route from oil tank to oil pump is blocked.
a. Ventilation hole on the tank cover is blocked.
Note:
1.When removing oil pump, do not drop any unexpected objects into the oil pipe.
2.Please release the air if there is air trapped in the oil pipe.
3.Locking torque of oil pump:0.8-1.2kg-m
3.Removing oil pump.
a. Remove the luggage and rear bracket.
b. Remove the input/output oil pipe.
c. Take out the oil pump by removing
The locking screw on oil pump and Oil gauge cable.
4.check oil pump.
Remove oil pump and check:
a. O-ring is distorted or not.
b. contactpart of crankcase is injured or not.
d. Oil pump body is damaged or not
e. The gears are damaged or not.
f. Check seal and see if there Is oil leakage or not.
g. Never dismantle oil pump it Can not function well after Dismantling.
5.Assemble the oil pump.
a. Assemble the oil pump by reversing
Above procedure.
O-ring of oil pump sho uld be lubricated by Grease or oil, then place on cankcase.
The contact surface of oil pump and crank Case should be assembled firmly.
The gears of oil pump should be lubriCated by grease.
b. Be sure oil pump screw is tightened nitely Locking torque:0.8~1.2kg-m
6.Releasing air in the oil pump.
(a)Fill up specific amount of oil to oil tank.
(b)Place dry cloth under the oil pump.
© Remove oil pipe.
(d)Use injector to fill up the oil in the oil pump body and oil pipe. Be sure the oil pipe and oil pump are full of oil before assembling.
(e)After assembling, check if there is still air trapped in the oil pipe.
~希望能幫到你~
