石光上林 wrote:
感謝您，這樣要對比方...(恕刪)
升級韌體是我要自己升級嗎
去哪兒下載@@?
a7533sys wrote:
有變了耶只是還是沒破...(恕刪)
上傳是絕對夠了
第一頁athony大大單線上傳的power有開到14.3，現在你才-3dbm
我看你的衰減，應該是夠單線100M，只是需要跳到VES1724的vdsl switch上
也许是一场难圆的梦
一场没有结局的梦
多少的笑语飞散在风中
又围绕在我耳边
石光上林 wrote:
應該離您房子120公...(恕刪)
請問怎查光化箱在哪
Statistics -- VDSL
============================================================================
VDSL Training Status: Showtime
VDSL Profile: Profile 17a
Traffic Type: PTM Mode
============================================================================
VDSL Port Details Upstream Downstream
Line Rate: 2.234 Mbps 6.468 Mbps
Actual Net Data Rate: 2.176 Mbps 6.398 Mbps
Trellis Coding: ON ON
SNR Margin: 26.6 dB 20.4 dB
Actual Delay: 4 ms 7 ms
Transmit Power: - 7.9 dBm - 8.9 dBm
Receive Power: -22.1 dBm -16.4 dBm
Actual INP: 2.0 symbols 24.0 symbols
Total Attenuation: 14.7 dB 7.5 dB
Attainable Net Data Rate: 45.699 Mbps 49.260 Mbps
============================================================================
VDSL Band Status U0 U1 U2 U3 D1 D2 D3
Line Attenuation(dB): 1 .8 13.4 19.0 N/A 7 .2 15.8 24.8
Signal Attenuation(dB): 1 .8 13.2 19.4 N/A 7 .2 15.8 24.8
SNR Margin(dB): 28.6 26.6 26.6 N/A 20.5 0 .0 20.1
Transmit Power(dBm):-22.6 -19.3 -7 .9 N/A -9 .3 -128.0 -19.8
============================================================================
Since Link time = 41 min 17 sec
FEC: 0 0
CRC: 0 0
ES: 0 0
SES: 0 0
UAS: 0 0
LOS: 0 0
LOF: 0 0
LOM: 0 0
Latest 15 minutes time = 12 min 2 sec
FEC: 0 0
CRC: 0 0
ES: 0 0
SES: 0 0
UAS: 0 0
LOS: 0 0
LOF: 0 0
LOM: 0 0
Previous 15 minutes time = 15 min 0 sec
FEC: 0 0
CRC: 0 0
ES: 0 0
SES: 0 0
UAS: 0 0
LOS: 0 0
LOF: 0 0
LOM: 0 0
Latest 1 day time = 42 min 2 sec
FEC: 0 0
CRC: 0 0
ES: 0 0
SES: 0 0
UAS: 44 44
LOS: 0 0
LOF: 0 0
LOM: 0 0
Previous 1 day time = 0 sec
FEC: 0 0
CRC: 0 0
ES: 0 0
SES: 0 0
UAS: 0 0
LOS: 0 0
LOF: 0 0
LOM: 0 0
Total time = 42 min 17 sec
FEC: 0 0
CRC: 0 0
ES: 0 0
SES: 0 0
UAS: 44 44
LOS: 0 0
LOF: 0 0
LOM: 0 0
============================================================================
