自從發現可樂龍大大的這篇文章後，就努力的在網路上尋找商品，就在上個星期六，幸運的以15000元購買到JVC 50T 4K 電視，8月供裝雖是二手但依然如新，而且賣家還讓我當場測試有無亮暗點與系統是否正常才完成交易，在此也一併感謝此賣家。
依照可樂龍大大分享的方式，一一的完成安裝， 原本只是將它定位為電腦的50吋4KLED液晶顯示器，沒想到的確是物超所值讓人驚艷， 就這樣鼓起勇氣 另外又再以19500元買了JVC 55T 4K 希望會有更好的效果。
下面是用EnTech的Monitor Asset Manager抓出EDID 資料, HDMI頻寬確定是300Mhz
Monitor #1 [Real-time 0x0061]
Model name............... 50T
Manufacturer............. AMR
Plug and Play ID......... AMRA01B
Manufacture date......... 2015, ISO week 18
Filter driver............ None
-------------------------
EDID revision............ 1.3
Input signal type........ Digital
Color bit depth.......... Undefined
Display type............. RGB color
Screen size.............. 1100 x 620 mm (49.7 in)
Power management......... Not supported
Extension blocs.......... 1 (CEA-EXT)
-------------------------
DDC/CI................... Not supported
Color characteristics
Default color space...... Non-sRGB
Display gamma............ 2.20
Red chromaticity......... Rx 0.644 - Ry 0.334
Green chromaticity....... Gx 0.300 - Gy 0.630
Blue chromaticity........ Bx 0.153 - By 0.067
White point (default).... Wx 0.272 - Wy 0.295
Additional descriptors... None
Timing characteristics
Horizontal scan range.... 31-70kHz
Vertical scan range...... 20-77Hz
Video bandwidth.......... 300MHz
CVT standard............. Not supported
GTF standard............. Not supported
Additional descriptors... None
Preferred timing......... Yes
Native/preferred timing.. 3840x2160p at 30Hz (16:9)
Modeline............... "3840x2160" 297.000 3840 4016 4192 4400 2160 2165 2173 2250 +hsync +vsync
Standard timings supported
720 x 400p at 70Hz - IBM VGA
640 x 480p at 60Hz - IBM VGA
640 x 480p at 75Hz - VESA
800 x 600p at 60Hz - VESA
800 x 600p at 72Hz - VESA
800 x 600p at 75Hz - VESA
1024 x 768p at 60Hz - VESA
1024 x 768p at 70Hz - VESA
1024 x 768p at 75Hz - VESA
EIA/CEA-861 Information
Revision number.......... 3
IT underscan............. Not supported
Basic audio.............. Supported
YCbCr 4:4:4.............. Supported
YCbCr 4:2:2.............. Supported
Native formats........... 1
Detailed timing #1....... 3840x2160p at 30Hz (16:9)
Modeline............... "3840x2160" 297.000 3840 4016 4192 4400 2160 2165 2173 2250 -hsync -vsync
Detailed timing #2....... 1920x1080p at 60Hz (16:9)
Modeline............... "1920x1080" 148.500 1920 2008 2052 2200 1080 1084 1089 1125 -hsync -vsync
CE video identifiers (VICs) - timing/formats supported
"1920x1080" 148.500 1920 2008 2052 2200 1080 1084 1089 1125 -hsync -vsync
720 x 480p at 60Hz - EDTV (16:9, 32:27)
1280 x 720p at 60Hz - HDTV (16:9, 1:1)
1920 x 1080i at 60Hz - HDTV (16:9, 1:1)
1920 x 1080p at 60Hz - HDTV (16:9, 1:1)
1920 x 1080p at 24Hz - HDTV (16:9, 1:1)
720 x 576i at 50Hz - Doublescan (4:3, 16:15)
720 x 576p at 50Hz - EDTV (16:9, 64:45)
1280 x 720p at 50Hz - HDTV (16:9, 1:1)
1920 x 1080i at 50Hz - HDTV (16:9, 1:1)
1920 x 1080p at 50Hz - HDTV (16:9, 1:1)
1920 x 1080p at 50Hz - HDTV (16:9, 1:1)
1920 x 1080p at 50Hz - HDTV (16:9, 1:1)
640 x 480p at 60Hz - Default (4:3, 1:1)
NB: NTSC refresh rate = (Hz*1000)/1001
CE audio data (formats supported)
LPCM 2-channel, 16/24 bit depths at 32/44/48 kHz
AC-3 6-channel, 640k max. bit rate at 32/44/48 kHz
CE speaker allocation data
Channel configuration.... 2.0
Front left/right......... Yes
Front LFE................ No
Front center............. No
Rear left/right.......... No
Rear center.............. No
Front left/right center.. No
Rear left/right center... No
Rear LFE................. No
CE vendor specific data (VSDB)
IEEE registration number. 0x000C03
CEC physical address..... 2.0.0.0
Supports AI (ACP, ISRC).. No
Supports 48bpp........... No
Supports 36bpp........... Yes
Supports 30bpp........... No
Supports YCbCr 4:4:4..... Yes
Supports dual-link DVI... No
Maximum TMDS clock....... 300MHz
Audio/video latency (p).. n/a
Audio/video latency (i).. n/a
HDMI video capabilities.. Yes
EDID screen size......... No additional info
3D formats supported..... Not supported
