adrianhsd wrote:
3770K 配上 MSI 主機板阿
難得看到M01有MSI 主機板的測試文
碰巧小弟也要配3770K+MSI 主機板，以換掉使用了9年的電腦
不過這次的大升級，沒有考慮到配獨顯，暫時用內顯先撐一陣子
我是從MSI改用DR MOS之後，主機板都用MSI的了
P55-GD80、P67A-GD65、P67A-GD80...
我暫時也是用HD4000，等六月以後看看 AMD 7870有沒有降價再考慮購買
創見DDR3-1333 Hynix顆粒4條4G，共16G超頻至DDR3-2200 11-13-13-35
MemTest燒機一個多小時終於跑完100%
當初一條600元買的記憶體，十分超值~XD
另外拿手邊的Team DDR3-2133 4G*2 跑DDR3-2600 10-12-12-33
意思意思跑個LinX 三圈
DDR3-2600 10-12-12-33 記憶體頻寬測試
Team DDR3-2133 4G*2 跑DDR3-2666 10-12-12-31
DDR3-2666 10-12-12-31記憶體頻寬測試
這次的Ivy平台的記憶體超頻變得很容易
調整記憶體時脈、電壓、CL參數、tRCD參數、tRP參數就可以很容易把記憶體頻率拉上去
液晶螢幕小常識
http://www.mobile01.com/topicdetail.php?f=350&t=539384
使用變電家測試整台電腦的耗電量
CPU：INTEL i7-3770K
CPU Cooler：Prolimatech Super Mega + sanyo denki120(2200rpm)
主機板：MSI Z77A-GD65
記憶體：創建 DDR3-1333 4G*2 (hyinx 146EA顆粒)
2顆40G SSD跑RAID0
1顆WD 640G 硬碟
1顆WD 1TB 硬碟
1顆WD 1.5TB 硬碟
2個機殼的12公分風扇
Power：Seasonic X-650W
預設時脈3.7G
待機耗電量 51W -71W
1核心燒機 71W
2核心燒機 91W
3核心燒機 101W
4核心燒機 110W
5核心燒機 113W
6核心燒機 116W
7核心燒機 117W
8核心燒機 119W
4.5G 1.3V(CPU-Z 1.28V)
待機 79W
OCCT 100%燒機 151W
液晶螢幕小常識
http://www.mobile01.com/topicdetail.php?f=350&t=539384
---------------------------------------
x264 HD BENCHMARK 5.0 RESULTS
---------------------------------------
Please do NOT compare it with older versions of the benchmark!
Please copy/paste everything below the line to to report your data
to http://forums.techarp.com/reviews-articles/26957-x264-hd-benchmark-5-0-a.html
^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^
Results for x264.exe r2200
x264 Benchmark: 64-bit
==========================
Pass 1
------
encoded 11812 frames, 71.49 fps, 7754.10 kb/s
encoded 11812 frames, 72.08 fps, 7753.92 kb/s
encoded 11812 frames, 72.03 fps, 7754.06 kb/s
encoded 11812 frames, 71.92 fps, 7753.99 kb/s
Pass 2
------
encoded 11812 frames, 15.79 fps, 8002.08 kb/s
encoded 11812 frames, 15.85 fps, 8002.24 kb/s
encoded 11812 frames, 15.53 fps, 8002.20 kb/s
encoded 11812 frames, 15.82 fps, 8002.24 kb/s
System Details
--------------
Name Intel Core i7 3770K
Codename Ivy Bridge
Specification Intel(R) Core(TM) i7-3770K CPU @ 3.50GHz
Core Stepping E1
Technology 22 nm
Stock frequency 3500 MHz
Core Speed 4500.0 MHz
Northbridge Intel Ivy Bridge rev. 09
Southbridge Intel Z77 rev. 04
CAS# latency (CL) 10.0
RAS# to CAS# delay (tRCD) 11
RAS# Precharge (tRP) 11
Cycle Time (tRAS) 29
Command Rate (CR) 2T
Memory Frequency 800.0 MHz (1:6)
Memory Type DDR3
Memory Size 16384 MBytes
Channels Dual
Windows Version Microsoft Windows 7 (6.1) Enterprise Edition 64-bit
(Build 7600)
Number of processors 1
Number of threads 8
Number of threads 8 (max 16)
L2 cache 4 x 256 KBytes, 8-way set associative, 64-byte line
size
Instructions sets MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, EM64T,
VT-x, AES, AVX
Package (platform ID) Socket 1155 LGA (0x1)
---------------------------------------
x264 FHD Benchmark 1.01 X64
---------------------------------------
x264.exe --demuxer-threads (LOGICAL_CORES) -o NUL SVT_1080p50.mkv
ffms [info]: 1920x1080p 1:1 @ 50/1 fps (vfr)
x264 [info]: using SAR=1/1
x264 [info]: using cpu capabilities: MMX2 SSE2Fast SSSE3 FastShuffle SSE4.2
x264 [info]: profile High, level 4.2
x264 [info]: cabac=1 ref=3 deblock=1:0:0 analyse=0x3:0x113 me=hex subme=7 psy=1
fade_compensate=0.00 psy_rd=1.00:0.00 mixed_ref=1 me_range=16 chroma_me=1 trelli
s=1 8x8dct=1 cqm=0 deadzone=21,11 fast_pskip=1 chroma_qp_offset=-2 threads=12 sl
iced_threads=0 nr=0 decimate=1 interlaced=0 bluray_compat=0 constrained_intra=0
bframes=3 b_pyramid=2 b_adapt=1 b_bias=0 direct=1 weightb=1 open_gop=0 weightp=2
keyint=250 keyint_min=25 scenecut=40 intra_refresh=0 rc_lookahead=40 rc=crf mbt
ree=1 crf=23.0000 qcomp=0.60 qpmin=0 qpmax=69 qpstep=4 ip_ratio=1.40 aq=1:1.00
x264 [info]: started at Sat Jun 02 21:41:23 2012
x264 [info]: frame I:10 Avg QP:25.24 size:293382
x264 [info]: frame P:1242 Avg QP:28.43 size: 90351
x264 [info]: frame B:1248 Avg QP:31.32 size: 19907
x264 [info]: consecutive B-frames: 8.7% 66.6% 23.2% 1.6%
x264 [info]: mb I I16..4: 3.6% 76.6% 19.8%
x264 [info]: mb P I16..4: 0.1% 4.7% 0.8% P16..4: 38.2% 25.5% 16.0% 0.0% 0
.0% skip:14.7%
x264 [info]: mb B I16..4: 0.0% 0.4% 0.0% B16..8: 48.1% 6.2% 1.9% direct:
4.2% skip:39.1% L0:36.0% L1:49.9% BI:14.1%
x264 [info]: 8x8 transform intra:83.2% inter:58.4%
x264 [info]: coded y,uvDC,uvAC intra: 90.8% 82.8% 56.9% inter: 30.4% 19.6% 4.0%
x264 [info]: i16 v,h,dc,p: 17% 37% 10% 36%
x264 [info]: i8 v,h,dc,ddl,ddr,vr,hd,vl,hu: 11% 25% 16% 5% 7% 6% 12% 6% 12%
x264 [info]: i4 v,h,dc,ddl,ddr,vr,hd,vl,hu: 15% 21% 13% 7% 8% 7% 11% 7% 11%
x264 [info]: i8c dc,h,v,p: 52% 26% 15% 7%
x264 [info]: Weighted P-Frames: Y:1.0% UV:0.1%
x264 [info]: ref P L0: 70.4% 21.8% 5.9% 2.0% 0.0%
x264 [info]: ref B L0: 90.8% 7.8% 1.4%
x264 [info]: ref B L1: 95.6% 4.4%
x264 [info]: kb/s:22399.00
encoded 2500 frames, 21.81 fps, 22399.00 kb/s
x264 [info]: ended at Sat Jun 02 21:43:18 2012
x264 [info]: encoding duration 0:01:55
液晶螢幕小常識
http://www.mobile01.com/topicdetail.php?f=350&t=539384
x264 HD BENCHMARK 5.0 RESULTS (4.5G 4C4T)(在BIOS關閉HT功能，CPU只跑4核心4執行緒)
---------------------------------------
^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^
Results for x264.exe r2200
x264 Benchmark: 64-bit
==========================
Pass 1
------
encoded 11812 frames, 56.56 fps, 7752.29 kb/s
encoded 11812 frames, 63.94 fps, 7752.34 kb/s
encoded 11812 frames, 64.44 fps, 7752.36 kb/s
encoded 11812 frames, 64.21 fps, 7752.32 kb/s
Pass 2
------
encoded 11812 frames, 13.28 fps, 8002.74 kb/s
encoded 11812 frames, 13.29 fps, 8002.69 kb/s
encoded 11812 frames, 13.36 fps, 8002.82 kb/s
encoded 11812 frames, 13.30 fps, 8002.74 kb/s
System Details
--------------
Name Intel Core i7 3770K
Codename Ivy Bridge
Specification Intel(R) Core(TM) i7-3770K CPU @ 3.50GHz
Core Stepping E1
Technology 22 nm
Stock frequency 3500 MHz
Core Speed 4499.9 MHz
Northbridge Intel Ivy Bridge rev. 09
Southbridge Intel Z77 rev. 04
CAS# latency (CL) 10.0
RAS# to CAS# delay (tRCD) 11
RAS# Precharge (tRP) 11
Cycle Time (tRAS) 29
Command Rate (CR) 2T
Memory Frequency 800.0 MHz (1:6)
Memory Type DDR3
Memory Size 16384 MBytes
Channels Dual
Windows Version Microsoft Windows 7 (6.1) Enterprise Edition 64-bit (Build 7600)
Number of processors 1
Number of threads 4
Number of threads 4 (max 16)
L2 cache 4 x 256 KBytes, 8-way set associative, 64-byte line size
Instructions sets MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, EM64T, VT-x, AES, AVX
Package (platform ID) Socket 1155 LGA (0x1)
---------------------------------------
x264 HD BENCHMARK 5.0 RESULTS (3.7G 4C8T)
---------------------------------------
^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^
Results for x264.exe r2200
x264 Benchmark: 64-bit
==========================
Pass 1
------
encoded 11812 frames, 60.12 fps, 7754.08 kb/s
encoded 11812 frames, 60.05 fps, 7754.15 kb/s
encoded 11812 frames, 59.42 fps, 7753.94 kb/s
encoded 11812 frames, 59.94 fps, 7754.07 kb/s
Pass 2
------
encoded 11812 frames, 13.01 fps, 8002.30 kb/s
encoded 11812 frames, 13.09 fps, 8002.11 kb/s
encoded 11812 frames, 13.07 fps, 8002.25 kb/s
encoded 11812 frames, 13.10 fps, 8002.16 kb/s
System Details
--------------
Name Intel Core i7 3770K
Codename Ivy Bridge
Specification Intel(R) Core(TM) i7-3770K CPU @ 3.50GHz
Core Stepping E1
Technology 22 nm
Stock frequency 3500 MHz
Core Speed 3700.1 MHz
Northbridge Intel Ivy Bridge rev. 09
Southbridge Intel Z77 rev. 04
CAS# latency (CL) 10.0
RAS# to CAS# delay (tRCD) 11
RAS# Precharge (tRP) 11
Cycle Time (tRAS) 29
Command Rate (CR) 2T
Memory Frequency 800.1 MHz (1:6)
Memory Type DDR3
Memory Size 16384 MBytes
Channels Dual
Windows Version Microsoft Windows 7 (6.1) Enterprise Edition 64-bit (Build 7600)
Number of processors 1
Number of threads 8
Number of threads 8 (max 16)
L2 cache 4 x 256 KBytes, 8-way set associative, 64-byte line size
Instructions sets MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, EM64T, VT-x, AES, AVX
Package (platform ID) Socket 1155 LGA (0x1)
x264 HD BENCHMARK 5.0 以"我是傳奇"的1080P預告片進行轉檔測試
i7-3770K在4C8T時4.5G轉檔效能較3.7G高約18%~22%
若時脈同為4.5G，4C8T轉檔效能較4C4T高約12%~26%
4.5G 4C4T比3.7G 4C8T轉檔效能差異 -5%~8%
結果顯示CPU在轉檔時，高時脈較多執行緒重要，當然最好是執行緒越多、時脈越高會更好~XD
測試程式下載：
x264 HD Benchmark 5.0
aviSynth 2.5.8
