LHR guide T-Rex has partial LHR unlock functionality for 30xx GPUs mining ethash (~70% of full hashrate).
In order to enable LHR mode, you need to explicitly tell the miner which GPUs are LHR and which are not. This is done by specifying --lhr-tune parameter which takes values from 0 to 8: 0 - disabled (use for non-LHR cards) 1 - lowest hashrate, low chance of LHR lock 4 - recommended starting value for most LHR cards 8 - highest hashrate, high chance of LHR lock It can also be set for each GPU separately, e.g. --lhr-tune 0,0,4,0 - this will tell the miner that the third GPU is LHR and that it needs to start with the tuning value of 4, while the rest of the cards are non-LHR. HiveOS equivalent would be "lhr-tune": "0,0,4,0"
It's important not to set intensity values manually as that may interfere with the unlocking algorithm.
The miner will try to achieve reasonable hashrate levels using the provided settings, and if that's not possible, will start aiming lower. During this process the reported hashrate will fluctuate and mostly stay on the lower side because every LHR lock will cause the miner to pause for 20 seconds to unlock the GPU, so you may need to wait till it finds stable settings.
Don't change your overclock settings too much while the miner is running, particularly be careful with the changes that may result in a rapid hashrate drop, like reducing memory overclock or decreasing power limit significantly (all during mining) - this can trick the miner into thinking the LHR has kicked in.
3060 rev.1 cards are not given any special treatment, and you're better off running them with 470.05 driver as before.
-a, --algo Specify the hash algorithm to use. autolykos2 etchash ethash firopow kawpow mtp mtp-tcr multi octopus progpow progpow-veil progpow-veriblock progpowz tensority --coin [Ethash, ProgPOW] Set coin name. Helps avoid DAG rebuilds when switching back from a dev fee session. Example: "eth" for Ethereum, "zil" for Zilliqa. --extra-dag-epoch Allocate extra DAG at GPU for specified epoch. Can be useful for dual mining of coins like Zilliqa (ZIL). (eg: --extra-dag-epoch 0) Can be set for each GPU separately by using comma separated list of values (set to -1 for the GPUs that should not allocate the extra DAG). --nonce-start [Ethash, ProgPOW] Starting nonce for the solution search. --nonce-range-size [Ethash, ProgPOW] Nonce range size for nonce search. The range will be split between all devices. -d, --devices Comma separated list of CUDA devices to use. Device IDs start counting from 0. --pci-indexing Sort devices by PCI bus ID. Device IDs start with 0. --ab-indexing Afterburner indexing (same as --pci-indexing but starts from 1). -i, --intensity GPU intensity 8-25 (default: auto). Controls the GPU workload size, in other words how many nonces the miner is processing "in one go": N = 2 ^ intensity --low-load Low load mode (default: 0). 1 - enabled, 0 - disabled. Reduces the load on the GPUs if possible. Can be set to a comma separated string to enable the mode for a subset of the GPU list (eg: --low-load 0,0,1,0) --lhr-tune [Ethash] LHR tuning value that controls the maximum hashrate the miner tries to achieve for LHR cards (default: 0). Range from 0 to 8. 0 - disabled (use for non-LHR cards) 1 - lowest hashrate, low chance of LHR lock 4 - recommended value for most LHR cards 8 - highest hashrate, high chance of LHR lock Can be set for each GPU separately, e.g. "lhr-tune": "0,0,4,0" - this will set LHR tuning value to 4 for the third GPU. --kernel [Ethash] Choose CUDA kernel (default: 0). Range from 0 to 5. Set to 0 to enable auto-tuning: the miner will benchmark each kernel and select the fastest. Can be set to a comma separated list to apply different values to different cards. (eg: --kernel 2,1,1,3) The support for this parameter may later be extended to cover other algorithms. --gpu-init-mode Enables DAG sequential initialization (default: 0). 0 - all GPUs are initialized in parallel 1 - fully sequential initialization, one GPU at a time 2 - two GPUs at a time etc. --dag-build-mode [Ethash, ProgPOW, Octopus] Controls how DAG is built (default: 0). 0 - auto (miner will choose the most appropriate mode based on the GPU model) 1 - default (suitable for most graphics cards) 2 - recommended for 30xx cards to prevent invalid shares Can be set to a comma separated list to apply different values to different cards. (eg: --dag-build-mode 1,1,2,1) --keep-gpu-busy Continue mining even in case of pool connection loss. Useful when a GPU crashes during start/stop cycle that occurs when internet connection goes down.
-o, --url URL of the mining pool in the following format: <scheme>://<host>:<port> Supported schemes: stratum+tcp stratum+ssl stratum+http stratum2+tcp stratum2+ssl stratum2 is normally used by Nicehash, MiningPoolHub and other similar mining pools Example: stratum+tcp://eu1.ethermine.org:4444 stratum+ssl://zcoin.mintpond.com:3005 stratum2+tcp://daggerhashimoto.hk.nicehash.com:3353 -u, --user Username for mining server. -p, --pass Password for mining server. -w, --worker Worker name.
-r, --retries Number of times to retry if a network call fails. -R, --retry-pause Pause in seconds between retries. -T, --timeout Network timeout, in seconds (default: 300) --time-limit Miner shutdown interval in seconds. (default: 0 - disabled)
--temperature-color Set temperature color for GPUs stat. Example: 55,65 - it means that temperatures above 55 will have yellow color, above 65 - red color. (default: 67,77) --temperature-limit GPU shutdown temperature. (default: 0 - disabled) --temperature-start GPU temperature to enable card after disable. (default: 0 - disabled)
-b, --api-bind-telnet IP:port for the miner API via telnet (default: 127.0.0.1:4068). Set to 0 to disable. For external access set IP to 0.0.0.0, in which case setting "--api-read-only" is recommended as well. --api-bind-http IP:port for the miner API via HTTP (default: 127.0.0.1:4067). Set to 0 to disable. For external access set IP to 0.0.0.0, in which case setting "--api-read-only" is recommended as well. --api-read-only Allow only read operations for API calls. -J --json-response Telnet API server will make json responses.
-N, --hashrate-avr Sliding window length in seconds used to compute average hashrate (default: 60). --sharerate-avr Sliding window length in seconds used to compute sharerate (default: 600). --gpu-report-interval GPU stats report frequency. Minimum is 5 sec. (default: 30 sec) --gpu-report-interval-s GPU stats report frequency in shares. 0 by default (disabled). -q, --quiet Quiet mode. No GPU stats at all. --hide-date Don't show date in console. --send-stales Don't drop stale shares. --validate-shares Validate shares before sending to a pool. Also enables share diff info.
--no-color Disable color output for console. --no-hashrate-report Disable hashrate report to pool. --no-nvml Disable NVML GPU stats. --no-strict-ssl Disable certificate validation for SSL connections. --no-watchdog Disable built-in watchdog. --watchdog-exit-mode Specifies the action "A" the watchdog should take if the miner gets restarted "N" times within "M" minutes. Format: N:M:A. Valid values: N: any positive integer, M: any positive integer, A: r(system reboot), s(system shutdown), e(miner exit) Actions "r" and "s" require running the miner with administrative privileges. Examples: 20:10:s - watchdog will shutdown the system if the miner gets restarted 20 times within any 10 minute interval 5:7:r - watchdog will reboot the system if the miner gets restarted 5 times within any 7 minute interval
-B, --benchmark Benchmark mode. --benchmark-epoch Epoch number used during benchmark (default: 0). Only applicable to DAG based algorithms except ProgPOW family. --benchmark-block Block number used during benchmark (default: 0). Only applicable for ProgPOW family of algorithms.
-P, --protocol-dump User protocol logging. -c, --config Load a JSON-format configuration file. -l, --log-path Full path of the log file. --cpu-priority Set process priority (default: 2) 0 idle, 2 normal to 5 highest.
--autoupdate Perform auto update whenever a newer version of the miner is available. --back-to-main-pool-sec Forces miner to switch back to main pool in case working with failover pool. Parameter is set in seconds. (default: 600) --exit-on-cuda-error Forces miner to immediately exit on CUDA error. --exit-on-connection-lost Forces miner to immediately exit on connection lost. --exit-on-high-power Forces miner to immediately exit on high power consumption. (eg: --exit-on-high-power 600 - exit in case of total power consumption exceeds 600W) --reconnect-on-fail-shares Forces miner to immediately reconnect to pool on N successively failed shares (default: 10).
--fork-at Forces miner to change algorithm on predefined condition (works only with built-in watchdog enabled) Epoch condition: <algo_name>=epoch:<epoch_number> (eg: --fork-at etchash=epoch:390). Block condition: <algo_name>=block:<block_number> (eg: --fork-at x16rv2=block:6526421). Time condition: <algo_name>=time:<yyyy-mm-ddthh:mm:ss>. Time must be set in UTC+0. (eg: --fork-at x16rv2=time:2019-10-01T16:00:00). To change main pool port you must write it right after algo: <algo_name>:<port_number> (eg: --fork-at x16rv2:4081=time:2019-10-01T16:00:00).
--script-start Executes user script right after miner start (eg: --script-start path_to_user_script) --script-exit Executes user script right before miner exit. --script-epoch-change Executes user script on epoch change. --script-crash Executes user script in case of miner crash. --script-low-hash Executes user script in case of low hash. Hash threshold is set in MegaHashes/second. Example: --script-low-hash script_to_activate:50 (activates "script_to_activate" script once total hashrate drops to 50MH/s)
------------------ GPU fine tuning (Windows & Linux) ----------------
--pl Sets GPU power limit (Windows - in percent, Linux - in Watts) Requires running the miner with administrative privileges. --lock-cclock Specifies desired locked GPU core clock speed in MHz. (default: 0 - disabled). Requires running the miner with administrative privileges. Example: --lock-cclock 1000 (applies clock 1000Mhz to all cards that support this functionality) --lock-cclock 1000,1300,0 (applies clock 1000Mhz to GPU #0, 1300MHz to GPU #1, ignore GPU #2)
--mt Memory tweak mode (default: 0 - disabled). Range from 0 to 6. General recommendation is to start with 1, and then increase only if the GPU is stable. The effect is similar to that of ETHlargementPill. Supported on Pascal GPUs with GDDR5 or GDDR5X memory only. Requires running the miner with administrative privileges. Can be set to a comma separated list to apply different values to different cards. Example: --mt 4 (applies tweak mode #4 to all cards that support this functionality) --mt 3,3,3,0 (applies tweak mode #3 to all cards except the last one)
------------------ GPU fine tuning (Windows only) ------------------
All options can be set to a comma separated list to apply different values to different cards. (default value for all options: 0 - not used) --fan Sets GPU fan speed in percent or target temperature (auto-fan). Valid formats: --fan N (where N is the fan speed) --fan t:N (where N is the target core temperature) --fan t:N[F1-F2] (same as above, but with the fan speed constrained by [F1%, F2%] range) --fan tm:N (where N is the target memory temperature) --fan tm:N[F1-F2] (same as above, but with the fan speed constrained by [F1%, F2%] range) Example: --fan 45,t:67,tm:95,t:69[45-100],tm:90[50-95] which translates to GPU #0: set fan speed to 45% GPU #1: maintain GPU core temperature at 67C GPU #2: maintain GPU memory temperature at 90C GPU #3: maintain GPU core temperature at 69C with the fan speed limited to [45%, 100%] range GPU #4: maintain GPU memory temperature at 90C with the fan speed limited to [50%, 95%] range Note: fan speeds are limited to [0%, 100%] range in auto-fan mode by default. --cclock Sets GPU core clock offset in MHz. Requires running the miner with administrative privileges. Will be set to 0 on exit and during DAG rebuild. --mclock Sets GPU memory clock offset in MHz. Requires running the miner with administrative privileges. Will be set to 0 on exit and during DAG rebuild. --cv Sets GPU core voltage in percent. Must be within [0, 100] range. Use it only in case you know what you are doing! Requires running the miner with administrative privileges. --lock-cv Specifies desired GPU core voltage in mV. (default: 0 - disabled). Requires running the miner with administrative privileges. --pstate Sets GPU P-state. Valid values: p0. Requires running the miner with administrative privileges.
--version Display version information and exit. -h, --help Display this help text and exit. </port_number></algo_name></yyyy-mm-ddthh:mm:ss></algo_name></block_number></algo_name></epoch_number></algo_name></port></host></scheme>
t-rex.exe -a ethash -o stratum+tcp://eu1.ethermine.org:4444 -u YOURWALLET -p x -w ruvus --lock-cclock 1160 --mclock 1400 --fan 80 --kernel 0 --coin eth --gpu-report-interval 5 --dag-build-mode 2 --intensity 25
