Monia wrote:
這個功能讚喔~感謝分...(恕刪)
CX5會6線?! 我在做白日夢~~
731-01-03 B0 B1 B2 B3 (checksum) in HEX
B0 - wireless mode lock/unlock is ONLY displayed on monitor (for example it is possible to configure only display the "unlock Mode"(step-by-step opening) or together with "Lock when leaving car":
b7 - 0 or 1 = function is not known
b6 - 0 or 1 = function is not known
b5 - 0 or 1 = function is not known
b4 - 0 or 1 = function is not known
b3 - 0 or 1 = function is not known
b2 - 0 or 1 = function is not known
b1 - 0 or 1 = function is not known
b0 - 0 or 1 = function is not known
Study IC:
720-04-01 B0 B1 B2 B3 B4 B5(checksum) in HEX
B0:B1 - it is checksum for full configuration of car (IC)
720-04-23 B0 B1 B2 B3 B4 B5(checksum) in HEX
B4 - it is (in BIN):
b7 - 0 or 1 = function is not known
b6 - 0 or 1 = 1 - Cruise Control with LIM
b5 - 0 or 1 = 1 - Standard Cruise Control/MRCC
b4 - 0 or 1 = 1 - W/O Cruise Control/MRCC
b3 - 0 or 1 = function is not known
b2 - 0 or 1 = function is not known
b1 - 0 or 1 = function is not known
b0 - 0 or 1 = function is not known
720-04-27 B0 B1 B2 B3 B4 B5(checksum) in HEX
B2 - it is (in BIN):
b7 - 0 or 1 = function is not known
b6 - 0 or 1 = function is not known
b5 - 0 or 1 = function is not known
b4 - 0 or 1 = function is not known
b3 - 0 or 1 = 0 - analogue rear view camera W/O path assist lines or 1 - rear view camera with path assist lines (rear view camera with CAN bus)
b2 - 0 or 1 = function is not known
b1 - 0 or 1 = function is not known
b0 - 0 or 1 = function is not known
這2個是改什麼?
謝謝
johnlee.tw wrote:
您好,請問....
這2個是改什麼?
謝謝...(恕刪)
731-01-03 B0 B1 B2 B3 (checksum) in HEX
B0 - wireless mode lock/unlock is ONLY displayed on monitor (for example it is possible to configure only display the "unlock Mode"(step-by-step opening) or together with "Lock when leaving car":
這個應該就是指頂級版Keyless wireless感應式車門鎖的功能，
他的功能就是當設定選項開啟後，當駕駛熄火下車(並把Keyless帶在身上)，
關上車輛所有車門。當駕駛帶著Keyless離開車輛感應距離時，車門就會自動上鎖。
Study IC:
720-04-01 B0 B1 B2 B3 B4 B5(checksum) in HEX
B0:B1 - it is checksum for full configuration of car (IC)
720-04-23 B0 B1 B2 B3 B4 B5(checksum) in HEX
B4 - it is (in BIN):
b7 - 0 or 1 = function is not known
b6 - 0 or 1 = 1 - Cruise Control with LIM
b5 - 0 or 1 = 1 - Standard Cruise Control/MRCC
b4 - 0 or 1 = 1 - W/O Cruise Control/MRCC
b3 - 0 or 1 = function is not known
b2 - 0 or 1 = function is not known
b1 - 0 or 1 = function is not known
b0 - 0 or 1 = function is not known
720-04-27 B0 B1 B2 B3 B4 B5(checksum) in HEX
B2 - it is (in BIN):
b7 - 0 or 1 = function is not known
b6 - 0 or 1 = function is not known
b5 - 0 or 1 = function is not known
b4 - 0 or 1 = function is not known
b3 - 0 or 1 = 0 - analogue rear view camera W/O path assist lines or 1 - rear view camera with path assist lines (rear view camera with CAN bus)
b2 - 0 or 1 = function is not known
b1 - 0 or 1 = function is not known
b0 - 0 or 1 = function is not known
這個可能是：
1.- Cruise Control with LIM? 定速巡航控制包含lim?(Limit速限功能??)
2.- Standard Cruise Control/MRCC 標準MRCC巡航功能開啟
3.- W/O Cruise Control/MRCC 無定速巡航與MRCC功能
4.- analogue rear view camera W/O path assist lines or 1 - rear view camera with path assist lines (rear view camera with CAN bus) 帶轉角輔助倒車顯影功能/不帶轉角輔助倒車顯影功能
