MAGNI: $99
DISCRETE HEADPHONE AMPLIFIER | CLASS AB | HIGH OUTPUT
MODI: $99
USB ASYNC DAC | 32 BIT AKM4396 D/A | ACTIVE FILTER STAGE
In stock. Orders placed now ship in 1-3 days.
Statement AMP和DAC毫無消息, 倒是跳出了入門階級
)
MODI DAC
Specifications
Sampling Rates: 16/44.1 to 24/96, including 24/88.2
Frequency Response: 20Hz-20Khz, -0.1db
Output Level, Maximum: 1.5V RMS
THD: Less than 0.004%, 20Hz-20KHz, at 1.6V RMS
IMD: Less than 0.006%, CCIR
SNR: More than 100db, unweighted, referenced to 1V RMS
Crosstalk: -80dB, 20-20kHz
Output Impedance: 75 ohms
Power Supply: USB powered, 120mA draw
Size: 5 x 3.5 x 1.25”
Weight: 1 lb
MAGNI AMP
Specifications
Frequency Response: 20Hz-20Khz, -0.1db, 2Hz-200KHz, -3dB
Maximum Power, 32 ohms: 1.2W
Maximum Power, 50 ohms: 1.0W
Maximum Power, 300 ohms: 260mW
Maximum Power, 600 ohms: 130mW
THD: Less than 0.005%, 20Hz-20KHz, at 1V RMS
IMD: Less than 0.007%, CCIR
SNR: Greater than 100db, unweighted, referenced to 1V RMS
Crosstalk: -70dB, 20 Hz-20KHz
Output Impedance: Less than 0.1 ohms
Gain: 5 (14db)
Topology: Fully discrete FET/bipolar, Class AB, DC coupled throughout
Protection: standard failsafe DC power input and muting relay
Power Supply: “wall wart” style 16VAC transformer, regulated +/- 15V rails
Power Consumption: 4W
Size: 5 x 3.5 x 1.25”
Weight: 1 lb
