basICColor DISCUS is supported by the following software products:
basICColor GmbH – basICColor display 5
Just Normlicht – adJUST monitor calibration 5
NEC – SpectraView Profiler 5
NEC – SpectraView II
SMARtt – softproofware
Remote Director
Serendipity Software – Veripress
Ugra Display Analysis and Certification Tools (UDACT)
EIZO – ColorNavigator 6.4.2
Quato Technology – iColor Display 3
––––––––––––––––––––––––––––––––––––––––––––––
SpectraCal – CalMAN v4
Display Calibrations LLC – ChromaPure
LIGHT ILLUSION – LightSpace CMS
––––––––––––––––––––––––––––––––––––––––––––––
basICColor GmbH – basICColor catch 4
Konica Minolta – Color Care
*********************************************************************
Functions
Measure Modes: Contact, tele and (ambient) light measurement
Optical Design: Highly sensitive colorimetric sensor with long-term stable thin-film glass filters, (Glasfilter), elaborate optical path for a large measure spot even in contact measurement
Aperture Angle In Contact And Tele Measurement: +/- 2°
Measure Spot In Contact: ø ca. 7 mm
Measure Spot In Tele Measurement, Distance 1m: ø ca. 7 cm
Measure Spot In Tele Measurement, Distance 10m: ø ca. 70 cm
Filter Wheel With 3 Positions:
• Black calibration position and protection for optics and laser pointer
•• Tele- and contact measurement position with filter thread for (lens hood, filter,...)
••• Integrated flat calotte for light measurement (Aperture angle 180°)
Contact Measurement: Mounting suspension with tape measure
Tele Measurement: 3/8” tripod socket, laserpointer, tape measure
Light Measurement: 3/8" tripod socket, laserpointer, coplanar unibody housing for measurement of lighting (lightbox, copy holder for proof prints, print control station...), flat calotte coplanar with paper surface at a distance of only 27mm from the surface, 2 positioning aids at 45 for repeatable appraisal of stray light
Housing: Aluminum Unibody For Added Robustness And Thermal Stability
Measurement Range: Luminance: 0,05 to 2.500 cd/qm
Chromaticity: 0,05 to 2.500 cd/qm
Accuracy: Luminance: +/-2% 1 digit ( 1 ~500cd/m2 )
Chromaticity: +/-0.002 Illuminant D65
Chromaticity: +/-0.0025 CCT 4000-15000K
Chromaticity: +/-0.0065 for other colors
Calibration: PTB traceable
Flickering: Measurement according to VESA standard
Interface: USB 2.0
Power Supply: 4,7 to 5,5V DC through USB adapter
Parameter Storage: 8 different base calibrations (5 used by factory settings), 22 positions for user calibrations
Speed: max. 10 measurements/s for low sensitivity, max. 4 measurements/s for high sensitivity
Temperature Compensation: 10°C to 50°C
USB Cable: ca. 1800mm
Dimensions: ø 97mm, height: 27mm, weight: 310g
---------------------------------------------------------------------------------------------------------
技術參數：
測量模式：接觸式測量，遠程測量，光測量
鏡頭結構：長期穩定的薄膜濾波器（玻璃過濾器）高靈敏度比色傳感器，用於測量較大的面積和接觸式測量複雜的光路
打開接觸和遠程測量的角度：+ / - 2度
在接觸測量點尺寸：直徑7毫米
在1m處遠程測量點尺寸：直徑7厘米
在10米距離光斑尺寸測量的長焦：ø70厘米
濾光輪有3個位置：遠程接觸測量和配件螺紋（鏡頭遮光罩，濾鏡，...）; 集成的扁平帽罩（鏡頭）的光測量（測量角度：180°）; 校準位置和測量和激光光學元件的保護帽
接觸式測量：懸掛集成捲尺
伸縮測量：3/8“螺紋，激光定位指針，捲尺
光測量：3/8“螺紋，激光定位指示器，平面平行的一體式機身，用於測量壓力控制站的標準光源展位和觀眾，休息照明，...），平半球罩（鏡頭）平行於這架專機，距離到飛機上，只有27毫米，2定位在45度的環境光側的再生評價
全鋁合金的生產條件下使用住房
亮度測量範圍：0.05至2500燭光/米色度：0.05至2500燭光/米
亮度精度：+ / -2％，1個數字（1〜500CD / M2）
色度：+ / -0002光源D65
色度：+ / -0.0025 CCT 4000-15000K
色度：+ / -0.0065其它顏色
校準：PTB溯源
閃爍：測量累計。VESA標準
接口：USB 2.0
電源：4.7至5.5 V DC通過USB連接器
參數設置：（前5出廠校準）8不同的基本校準，16存儲空間為個人校準，可以與底座校準相結合最多顯示128組合
測量速度：最大。10次測量/ s的低靈敏度，最大。4次測量/ s的高靈敏度
溫度補償：10度至50度
USB電纜長度：約1800mm
外形尺寸：寬：97毫米，身高：27毫米，重量：310克
耗材：測量激光定位和集成鏡頭，螺紋接頭3/8“1/4”暫停集成捲尺，口袋
