有小更新
pomolio wrote:
請教各位最近ROS做(恕刪)
可以參考這篇~~
https://www.mobile01.com/topicdetail.php?f=110&t=6145034
PORT 轉發 參考這篇... 不過要指定 進來的 pppoe是哪條線...
https://www.mobile01.com/topicdetail.php?f=110&t=5960682
pomolio wrote:嗯...ether5就只是接監視器，為何要新增bridge與vlan？
目前大致搞定了,今天(恕刪)
1.將ether5從原本的bridge1 port移除後，
在/ip address新增，將ether5設定為192.168.50.1/24
2.進入監視器後台，將監視器的ip設為192.168.50.2 / 255.255.255.0
gateway：192.168.50.1
3.設定路由標記/ip firewall mangle
add action=add-dst-to-address-list chain=prerouting in-interface=pppoe-out2 \
dst-address-type=local address-list=pppoe2 address-list-timeout=1w
add action=mark-connection chain=prerouting in-interface=pppoe-out2 \
new-connection-mark=pppoe2_conn src-address-type=!local
add action=mark-routing chain=prerouting connection-mark=pppoe2_conn \
in-interface=ether5 new-routing-mark=to_pppoe2
4.設定路由策略/ip route
add distance=1 gateway=pppoe-out2 routing-mark=to_pppoe2
5.設定nat映射和偽裝/ip firewall nat
add action=masquerade chain=srcnat out-interface=ether5 \
src-address=192.168.88.0/24 (假設bridge1=192.168.88.0/24)
add action=dst-nat chain=dstnat dst-address-list=pppoe2 \
to-addresses=192.168.50.2 src-address-type=!local
add action=masquerade chain=srcnat out-interface=pppoe-out2
yjohnny811 wrote:
新手查詢, 如果我(恕刪)
RB850G：
/interface bridge add name=bridge
/interface bridge port
add bridge=bridge interface=ether2 hw=yes
add bridge=bridge interface=ether3 hw=yes
add bridge=bridge interface=ether4 hw=yes
add bridge=bridge interface=ether5 hw=yes
/interface ethernet switch port
set switch1-cpu vlan-header=add-if-missing vlan-mode=fallback
set ether3 vlan-header=add-if-missing vlan-mode=fallback
set ether2 default-vlan-id=10 vlan-header=always-strip vlan-mode=fallback
set ether4 default-vlan-id=20 vlan-header=always-strip vlan-mode=fallback
set ether5 default-vlan-id=20 vlan-header=always-strip vlan-mode=fallback
/interface ethernet switch vlan
add ports=switch1-cpu,ether3,ether2 switch=switch1 vlan-id=10
add ports=switch1-cpu,ether3,ether4,ether5 switch=switch1 vlan-id=20
/interface vlan
add name=vlan10 vlan-id=10 interface=bridge
add name=vlan20 vlan-id=20 interface=bridge
hap：
/interface bridge add name=bridge
/interface bridge port
add bridge=bridge interface=wlan pvid=10
add bridge=bridge interface=ether1 hw=no pvid=10
add bridge=bridge interface=ether2 hw=no pvid=20
add bridge=bridge interface=ether3 hw=no pvid=20
add bridge=bridge interface=ether4 hw=no pvid=20
add bridge=bridge interface=ether5 hw=no
/interface bridge vlan
add bridge=bridge tagged=bridge,ether5 untagged=ether1,wlan vlan-ids=10
add bridge=bridge tagged=bridge,ether5 untagged=ether2,ether3,ether4 vlan-ids=20
/interface vlan
add name=vlan10 vlan-id=10 interface=bridge
add name=vlan20 vlan-id=20 interface=bridge
/interface bridge
set bridge vlan-filtering=yes
