chrisintaipei wrote:不會比較輕鬆，因為netwatch不能指定interface。
用 netwatch...(恕刪)
當您有多個wan時，還是得為router加policy-routing，
以確保封包能往不同wan送，進而得知連接的隧道是否有中斷的情形。
gfx wrote:
不得不說ROS在過...(恕刪)
所以基本上看來我的方法不太可行囉~只好在努力的研究看看囉!
ros有一個問題讓我也很悶,我買了4g網卡華為e3276,原本想說
插在公司的crs109上使用結果它都抓不到,以為是不支援
結果回家插我的ccr1036可以支援抓到,而公司軔體還6.27
家裡6.26結果不同答案,也不知在買一支e3272官方有寫的
去插crs109還是crs109根本就不支援4g網卡嗎???
真是難攪的ros
pctine wrote:
不管任何一套 fir...(恕刪)
大家好, 剛購入 RB850GX2, 但是使用上遇到困難, 急需幫忙
我的環境如下兩路中華電信 : 一路 300M/100M 固定IP, 一路 100M/40M PPPOE
兩路我設定負載均衡
PORT1 : WAN1 接 300M/100M 固定 IP
PORT2 : WAN2 接 100M/40M PPPOE
PORT3 : LAN1 接 HUB 設定 DHCP SERVER
PORT4 : LAN2
PORT5 : LAN3
LAN 目前 DHCP SERVER 不正常, 且 IP 無法綁定 MAC
SHCP POOL 設為 192.168.0.10-192.168.0.250
明明就綁定為 192.168.0.218, 而我的電腦永遠取得 POOL 最後一位 192.168.0.250
下面是我的設定檔:
------------------------------------------------------------------
# mar/29/2015 22:12:25 by RouterOS 6.27
# software id = 6A1T-IN9R
#
/interface ethernet
set [ find default-name=ether3 ] name=lan1
set [ find default-name=ether4 ] master-port=lan1 name=lan2
set [ find default-name=ether5 ] master-port=lan1 name=lan3
set [ find default-name=ether1 ] name=wan1
set [ find default-name=ether2 ] name=wan2
/interface pppoe-client
add add-default-route=yes disabled=no interface=wan2 keepalive-timeout=\
disabled name=pppoe-out2 password=xxxxxxxx user=xxxxxxx@hinet.net
/ip neighbor discovery
set wan1 discover=no
/ip pool
add name=dhcp ranges=192.168.0.10-192.168.0.250
add name=dhcp_pool1 ranges=192.168.0.10-192.168.0.250
/ip dhcp-server
add address-pool=dhcp_pool1 disabled=no interface=lan1 lease-time=3d name=\
dhcp1
/port
set 0 name=serial0
/ip address
add address=192.168.0.1/24 interface=lan1 network=192.168.0.0
add address=59.125.XX.109/24 interface=wan1 network=59.125.XX.0
/ip dhcp-client
add comment="default configuration" dhcp-options=hostname,clientid disabled=\
no interface=lan1
/ip dhcp-server lease
add address=192.168.0.112 client-id=DS151+_1 mac-address=00:11:32:3D:94:2D
add address=192.168.0.113 client-id=DS1515+_2 mac-address=00:11:32:3D:94:2E
add address=192.168.0.114 client-id=DS1515+_3 mac-address=00:11:32:3D:94:2F
add address=192.168.0.115 client-id=DS1515+_4 mac-address=00:11:32:3D:94:30
add address=192.168.0.151 client-id=Work01 mac-address=E0:3F:49:44:73:FC
add address=192.168.0.152 client-id=Work02 mac-address=14:DA:E9:EA:D1:12
add address=192.168.0.153 client-id=Work03 mac-address=14:DA:E9:EA:C8:EC
add address=192.168.0.154 client-id=Work04 mac-address=14:DA:E9:EA:D1:10
add address=192.168.0.155 client-id=Work05 mac-address=14:DA:E9:EA:D1:11
add address=192.168.0.156 client-id=Work06 mac-address=14:DA:E9:EA:CF:3A
add address=192.168.0.157 client-id=Work07 mac-address=14:DA:E9:EA:D1:15
add address=192.168.0.218 client-id=test_2 mac-address=00:15:17:8A:C6:85 \
server=dhcp1
add address=192.168.0.219 client-id=test mac-address=BC:5F:F4:47:35:0C server=\
dhcp1
add address=192.168.0.116 client-id=QNAP mac-address=00:08:9B:C5:66:17
/ip dhcp-server network
add address=192.168.0.0/24 comment="default configuration" dns-server=\
168.95.1.1,8.8.8.8 gateway=192.168.0.1 netmask=24
/ip dns
set allow-remote-requests=yes servers=168.95.1.1
/ip dns static
add address=192.168.88.1 name=router
/ip firewall filter
add chain=input comment="default configuration" protocol=icmp
add chain=input comment="default configuration" connection-state=\
established,related
add action=drop chain=input comment="default configuration" in-interface=wan1
add chain=forward comment="default configuration" connection-state=\
established,related
add action=drop chain=forward comment="default configuration" \
connection-state=invalid
add action=drop chain=forward comment="default configuration" \
connection-nat-state=!dstnat connection-state=new in-interface=wan1
/ip firewall mangle
add action=mark-connection chain=input in-interface=wan1 new-connection-mark=\
WAN1_conn
add action=mark-connection chain=input in-interface=pppoe-out2 \
new-connection-mark=WAN2_conn
add action=mark-routing chain=output connection-mark=WAN1_conn \
new-routing-mark=to_WAN1
add action=mark-routing chain=output connection-mark=WAN2_conn \
new-routing-mark=to_WAN2
add action=mark-connection chain=prerouting dst-address-type=!local \
in-interface=lan1 new-connection-mark=WAN1_conn \
per-connection-classifier=both-addresses-and-ports:2/0
add action=mark-connection chain=prerouting dst-address-type=!local \
in-interface=lan1 new-connection-mark=WAN2_conn \
per-connection-classifier=both-addresses-and-ports:2/1
add action=mark-routing chain=prerouting connection-mark=WAN1_conn \
in-interface=lan1 new-routing-mark=to_WAN1
add action=mark-routing chain=prerouting connection-mark=WAN2_conn \
in-interface=lan1 new-routing-mark=to_WAN2
/ip firewall nat
add action=masquerade chain=srcnat out-interface=wan1
add action=masquerade chain=srcnat out-interface=pppoe-out2
/ip route
add check-gateway=ping distance=1 gateway=59.125.xx.254 routing-mark=to_WAN1
add check-gateway=ping distance=1 gateway=pppoe-out2 routing-mark=to_WAN2
add distance=1 gateway=59.125.xx.254
add check-gateway=ping distance=1 gateway=59.125.xx.254
add check-gateway=ping distance=2 gateway=pppoe-out2
/system clock
set time-zone-name=Asia/Taipei
/system routerboard settings
set cpu-frequency=533MHz
/tool mac-server
set [ find default=yes ] disabled=yes
add interface=wan2
add interface=lan1
add interface=lan2
add interface=lan3
/tool mac-server mac-winbox
set [ find default=yes ] disabled=yes
add interface=wan2
add interface=lan1
add interface=lan2
add interface=lan3
